Input
Input Voltage: AC 230V
Frequency: 50–60 Hz
Max Electric Current: 4.5A
Power Capacity: 600W
Efficiency: 88%
Output Current
+5V: 20A
+3.3V: 20A
+12V1: 30A
+12V2: 30A
–12V: 0.5A
+5VSB: 3A
Connectors
• 1 × 24-pin ATX (with detachable 4-pin section)
• 1 × 8-pin EPS12V (with detachable 4-pin ATX12V section)
• 4 × 4-pin internal power (Molex)
• 5 × SATA (15-pin)
• 2 × 8-pin PCI-Express (with detachable 2-pin section)
• 1 × 4-pin FDD (mini-power)
Cooling System: 120 mm fan
Features: Thermal monitoring, short-circuit protection
Compliant Standards
TUV, CB, CCC, RoHS, GOST-R, S Mark, ErP Lot 6, RCM
Warranty: 2 years (limited)
Dimensions
Width: 15 cm
Depth: 14 cm
Height: 8.6 cm
Weight: 1.6 kg
