Supports 3rd Gen Intel 22nm CPUs and 2nd Gen Intel Core CPUs (LGA1155)
Chipset: Intel B75 Express
CPU Support: Intel Core i7/i5/i3, Pentium, Celeron (LGA1155)
BIOS: UEFI BIOS
Design: Ultra Durable 4 Classic, All Solid Capacitors
Memory: 2 x DDR3 DIMM, up to 16GB
Memory Support: DDR3 2200(OC)/1600/1333/1066 MHz, Dual Channel
Graphics: Integrated Intel HD Graphics
Video Outputs: 1 x D-Sub
Video Outputs: 1 x DVI-D (1920×1200 max)
Audio: Realtek ALC887, 2/4/5.1/7.1-channel
LAN: Realtek GbE 10/100/1000
PCI Slots: 1 x PCIe x16 (PCIe 3.0)
PCI Slots: 2 x PCIe x1 (PCIe 2.0)
Storage: 1 x SATA 6Gb/s, 5 x SATA 3Gb/s
USB: 4 x USB 3.0, 8 x USB 2.0
Internal Connectors: 24-pin ATX, 4-pin ATX 12V
Internal Connectors: CPU fan, system fan
Internal Connectors: Front panel, audio, USB 3.0, USB 2.0
Back Panel: PS/2 mouse, PS/2 keyboard
Back Panel: D-Sub, DVI-D
Back Panel: 2 x USB 3.0, 4 x USB 2.0
Back Panel: RJ-45, 3 audio jacks
I/O Controller: iTE Controller Chip
Monitoring: Voltage, temperature, fan speed
BIOS Size: 64 Mbit AMI EFI BIOS
Features: @BIOS, Q-Flash, EasyTune, Smart Recovery 2
Features: Auto Green, ON/OFF Charge, Q-Share, EZ Setup
Software: Norton Internet Security, Intel Rapid Start
Software: Intel Smart Connect, Intel SBA
Operating System: Windows 8 / 7 / XP
