CPU Support: Intel Core i7 (LGA2011-3), L3 cache varies by CPU

Chipset: Intel X99 Express

Memory: 8 x DDR4 DIMM sockets, up to 64GB

Memory Architecture: Quad-channel

Memory Speeds: DDR4 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz

Memory Features: Non-ECC, XMP support, RDIMM 1Rx8 (non-ECC mode)

Audio: Realtek ALC1150 HD Audio, 2/4/5.1/7.1 channels, S/PDIF Out

LAN: Intel Gigabit LAN (10/100/1000)

Expansion Slots: 2 x PCIe x16 (x16), 2 x PCIe x16 (x8), 3 x PCIe x1

Wireless: M.2 Socket 1 for Wi-Fi module

Multi-GPU Support: 4-Way / 3-Way / 2-Way AMD CrossFire / NVIDIA SLI

Storage (Chipset): 1 x M.2 (PCIe x2/x1 & SATA), 1 x SATA Express

SATA Ports: 6 x SATA 6Gb/s (RAID 0/1/5/10), 4 x sSATA 6Gb/s (AHCI/IDE)

USB: 4 x USB 3.0 + 8 x USB 2.0 via chipset

USB (Rear, Renesas Hub): 4 x USB 3.0

Internal Power: 24-pin ATX, 8-pin 12V, PCIe power connector

Internal Connectors: M.2, SATA Express, 10 x SATA, CPU fan, CPU_OPT fan, 3 system fans

Internal I/O: Front panel, front audio, USB 3.0 header, USB 2.0 headers, TPM header, Thunderbolt AIC header, Clear CMOS

Back Panel: PS/2 keyboard, PS/2 mouse, 6 x USB 3.0, 4 x USB 2.0, RJ45, optical S/PDIF, 5 audio jacks, Wi-Fi antenna holes

Monitoring: Voltage, CPU/System/Chipset temps, fan speed, overheating/fan-fail warnings, fan speed control

BIOS: AMI UEFI, DualBIOS, Q-Flash Plus

Special Features: APP Center, @BIOS, Ambient LED, EasyTune, Fast Boot, Cloud Station, ON/OFF Charge, Smart TimeLock, Smart Recovery 2, System Information Viewer, USB Blocker, V-Tuner, Q-Flash, Smart Switch, Xpress Install

Software Bundle: Norton Internet Security (OEM), Intel Smart Response Technology, cFosSpeed

OS Support: Windows 8.1 / 8 / 7

Form Factor: ATX – 30.5 cm x 24.4 cm
