Function: Control 1 x RS232 device via Ethernet or Internet
Serial Port: DB9 male
LAN Interface: 10BaseT / 100BaseTx Ethernet
Auto Discovery: Driver automatically detects NetCom devices
Configuration: Driver panels, serial port, Telnet, Web browser, SNMP
Automatic Mode Switching: Driver mode ↔ RAW mode
Supported Protocols: TCP/IP, UDP, Telnet, DHCP, ICMP, HTTP, SNMP v1/v2c/v3, DNS
Processor: ARM7 TDMI 50 MHz
I/O Controller: 16C550C or compatible
Memory: 8 MB SDRAM, 1 MB Flash
Connectors: RJ45 for LAN, DB9 male for serial
LAN: Auto-detecting 10BaseT / 100BaseTx
Serial Interface: RS232
Connector: DB9 male
Number of Ports: 1
Speed: Up to 460 kbps
Mode: RS232 full duplex
Signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND
Max Speed: 460 kbps
Parity: None, Even, Odd, Space, Mark
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
IRQ: None
I/O Address: None
Driver Mode: Virtual COM port via VScom Driver
TCP Raw Server: Accepts multiple incoming TCP connections
TCP Raw Client: Connects to multiple TCP hosts
TCP Advanced: User-defined advanced TCP modes
UDP Mode: Raw UDP with timeout & trigger functions
Null Modem Tunnel: Two NetCom devices operate as a virtual null modem
IP Modem: AT-command modem emulation to IP addresses
INF Driver: Provided for installation
Print Server: Supports serial printers via RFC1197
Installation Tool: Auto-discovers devices on LAN
Automatic Mode Switching: Auto-selects Driver or RAW mode
Advanced Configuration: Driver panel, NetCom Manager, Web, serial console, Telnet, SNMP
SNMP: VScom MIB included
DNS: Supported
Firewall: Special compatibility features
Firmware Update: Via Web, Telnet, or COM port
LED Indicators: Power, Tx, Rx, LAN Link, LAN Speed
Password Access: One unified password for all configuration functions
Power Requirements: 9–30V DC, 200 mA @ 12V
Power Adapter: 12V DC, 1A
Dimensions: 73 × 115 × 27 mm (W × L × H)
Dimensions with Ears: 101 × 121 × 27 mm
Operating Temperature: 0°C – 60°C
Storage Temperature: -20°C – 85°C
Case Material: SECC sheet metal (1 mm)
Weight: 0.2 kg
Approvals: FCC Class A, CE Class A
Environment: RoHS compliant
